行動電話連接元件 Components for mobile devices
RF switches & accessoires
3976.99.0030.001 Miniature straight female SMD RF antenna switch
Features
．Ultra low height
．10.000 mating cycles
．To application matched thickness of surface layers
．Robust design due to deep drawn housing
．Excellent guiding feature
．Size：D : 3.1、H : 1.75
Download drawing
Download datasheet
3926.99.0030.001 Miniature straight female SMD RF test switch
Features
．Ultra low height
．50 mating cycles
．Fully footprint compatible with MuRata MM 8430-2600B
．Robust design due to deep drawn housing
．Excellent guiding feature
．Size：D : 3.1、H : 1.75
4546.99.0030.001 Miniature straight female SMD RF test switch
Features
．Robust design
．20.000 mating cycles
．Watertight IP67
．Height and Interface easy to adjust acc. customer request
．Size：D : 4.19、H : 5.6
3724.99.0030.001 Right angle female SMD RF switch
Features
．One of the world's smallest angle switches
．Very compact and robust design
．Reversible polarity for flexible PCB layout
．For all cellular bands(GSM, GCS, PCS, UMTS and CDMA)
．Outstanding return loss values
．Minimum of 5.000 mating cycles
．Size：D : 2.6、H : 2.5、L : 5.8
Download drawing
Download datasheet
2421.99.0000.008 Straight female SMD RF antenna switch
Features
．Durable design for more than 20.000 mating cycles
．Increased contact security
．Compact and robust
．Outer gasket for better sealing properties
．For most. freq. bands(GSM, DCS, PCS and CDMA)
．Size：D : 4、H : 8
Download drawing
Download datasheet
2795.99.0030.001 Straight female SMD RF antenna switch
Features
．Durable and robust design for more than 20.000 mating cycles
．Proven design
．Excellent guiding features for car cradle applications
．For all freq. bands
．Size：D : 4.4、H : 2.5
Download drawing
Download datasheet
2984.99.0030.003 Straight male SMD antenna switch
Features
．Robust design for more than 20.000 mating cycles
．Excellent guiding features
．ESD protected
．For most freq. bands(GSM, DCS, PCS + CDMA)
．Size：D : 6.1、H :6.5
Download drawing
Download datasheet
